Beskrivning
-
- On-Wall Swivel Mounting Options
-
- 28″ x 8.6″ XStat™ CLS™ Transducer
-
- Slim Profile, 6.5″ Depth
-
- 6.5-inch Fiber Cone Woofer
-
- Bass Reflex Port
EGENSKAPER
|
Frequency Response
|
68–22,000 Hz ±3dB
|
|
Horizontal Dispersion
|
30°
|
|
Vertical Dispersion
|
28″ (71cm) line source
|
|
High Frequency Transducer
|
XStat™ CLS™ electrostaic transducer
|
|
» Panel Dimensions
|
28″ × 8.6″ (71.1 × 21.8cm)
|
|
» Radiating Area
|
241 in2(1,550 cm2)
|
|
Low Frequency Transducer
|
6.5″ (16.5cm) high excursion, fiber cone with extended throw drive assembly bass reflex
|
|
Sensitivity
|
90 dB/2.83 volts/meter
|
|
Impedance
|
6 Ohms, 1.3 @ 20kHz. Compatible with 4, 6, or 8 Ohm rated amplifiers.
|
|
Recommended Amplifier Power
|
20‒300 watts per channel
|
|
Crossover Frequency
|
530Hz
|
|
Components
|
Custom-wound E-I core transformer, air core coils, metal film capacitors
|
|
Inputs
|
Custom 5-way binding posts
|
|
Power Draw
|
Max: 2W each
|
|
Weight
|
24.5 lbs. (11.1 kg)
|
|
Dimensions
Garanti
|
48.8″ × 9.4″ × 6.5″
2År
|
